EZ Lock Pole Camera Mount Bracket

BR-MPM1

Best pole mount option for Dotworkz housings
  • Works with Dotworkz Camera Housings: D2, D3, S Type, STXL, BASH, Other Brands i.e. PELCO
  • Secures to poles with a minimum of 2” diameter
  • Angle Correction Plate can be added to correct the angle of the enclosure up to 10 degrees for non plum poles
  • Includes antenna mounts for adding additional Omni or yogi antennas
  • USA Made & Supported
  • Includes Friction Wraps for long term safety and ease of install
  • High Quality Pem Nuts backed

EZ Lock Pole Camera Mount Bracket BR-MPM1

Fast, Secure, No-Drill Install for Any Camera System

Looking for a faster, easier, and safer way to mount security cameras to a wide range of poles diameters ? The Dotworkz EZ Lock Pole Mount Bracket is the go-to mounting solution for installers who need speed and stability without the hassle of drilling.

This rugged, adjustable bracket system clamps securely to round or square poles using high-strength stainless steel bands. Whether you’re mounting PTZ, dome, fixed, or multi-sensor cameras, the EZ Lock keeps your gear locked down and aligned—saving you time on installs while protecting your equipment long-term.

Perfect For:

  • Construction and jobsite security cameras

  • Parking lots and school campuses

  • City surveillance and traffic monitoring

  • Temporary or rental camera kits

Works seamlessly with Dotworkz housings (D2, STXL, STYPE, BASH, D3 ), Axis, Hanwha, Hikvision, Sony, Panasonic, and more.

Replaces having to fab homemade mounts — this is your upgrade.

Key Features:

  • Quick-install, no-drill design saves hours on the job

  • Compatible with most Dotworkz housings and camera systems

  • Stainless steel band clamps included

  • Built-in anti-slip grip for rugged deployments

  • Weatherproof & corrosion-resistant construction

  • Ideal for both permanent and temporary camera installations

Specifications:

  • Material: Powder-coated aluminum bracket & stainless steel bands

  • Mounting Range: Fits poles 2" to 16" in diameter (round or square)

  • Weight Load: Supports up to 55 lbs

  • Dimensions: 9" x 6" mounting plate

  • Finish: Matte white powder coat

  • Included: Bracket, 2 stainless steel band clamps, friction bands



Accessories

Z-Bracket - PTZ / Static / Fixed Security Camera Housing Mount Bracket

Z-Bracket Rooftop Mount

Parapet Clamp System

  • No Drilling Required: Avoid costly roof penetrations
  • Supports wall and Corner thicknesses from 2" to 34"
  • Supports all major camera types and weights including Axis, Hanwha, Bosch, Panasonic and more, including axis cabinets, NEMA boxes, Starlink etc
  • Simplifies installs and lowers project expenses. No need for exterior access, lifts, or scaffolding
  • 100% Adjustable and can be field configured
  • Can be secured to top of parapet for added security
  • Replaces corner mounts and J mounts without wobble or unslightly dated aesthetics
  • Long Lasting High Quality Lightweight Powder Coated Aluminum
Security Camera Housing - Tilt Plate For Pole Mount Bracket

Tilt Plate For Pole Mount Bracket

BR-ACPM
