Dotworkz HD12 BASE CAMERA ENCLOSURE
IP66 Dust-Tight, Impact Tough Broadcast Camera Enclosure
Give your PTZ or long-lens box cam studio-grade armor without paying for weather-sealed bodies. The HD12 Core Chassis is an IP66 water-tight, impact-rated housing built for arenas, sound stages, convention halls, and other mild-climate venues.Built for studios, arenas, houses of worship, and any mild-climate venue where debris and bumps, not heat or cold, are the main threat.
Why Crews Pick HD12 Base:
- Lower Cost vs. Weather-Sealed CamerasSkip expensive factory-sealed bodies. Drop your preferred standard PTZ or long-lens box cam into the HD12 Core and get better protection for a fraction of the hardware price.
- Future-Proof & Upgrade-ReadyInterior rails, generous lens clearance, and oversized cable glands make camera swaps painless. When technology jumps from 1080p to 4K, SDI to IP, just unlock the hatch, slide the new rig in, and you’re live again in minutes.
- Broadcast Size InteriorFits full-frame PTZs or box cams plus wireless TX, power bricks, or SDI/Fiber converters, no cramming or cable kinks.
- Dust & Impact ArmorIP66-sealed, high-impact thermoplastic shell shakes off forklift dings, rigging knocks, and airborne dust keeping optics spotless and feeds uninterrupted.
- Zero Climate OverheadShips without heaters or coolers, trimming weight, power draw, and budget while still delivering rock-solid protection in mild environments.
- Fast, Tool-Free AccessQuick-latch front hatch lets techs swap cameras or cables in seconds no tiny screws to drop, no show-day delays.
- Expandable ProtectionNeed weather hardening later? Bolt on Dotworkz Heater-Blower or CoolDome™ kits later, no new housing required.
Specifications:
| Rating | IP66 |
| Interior Clear Space | 12″ Ø × 14″ D (fits mid to large pro PTZ & AI cams) |
| Empty Weight | ≈ 22 lb / 10 kg |
| Material | UV-stable, impact-rated thermoplastic |
| Access | Lockable, tool-free front hatch |
| Cable Entry | Four M25 glands + ¾-NPT knockout |
| Mounting | 4-point ⅜-16 pattern for pole, truss, rail, or wall adapters |
